Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production

Product Categories
Foshan Hesheng Machinery Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production

  • 1
  • 2
  • 3

Color : Customizable

Brand Name : Heling Machine

Certification : 10221508

Place of Origin : CHINA

MOQ : 1pcs

Price : Welcome to Inquire

Payment Terms : T/T

Supply Ability : 80+SET+PER month

Delivery Time : 30-40 Work days

Packaging Details : wooden box

Usage : Efficient Automation Fully automatic continuous operation, integrating multiple processes such as straightening, cutting, forming, and thread rolling, significantly improving production efficiency and reducing labor costs. Precision and Reliability Adoptin

Core selling points : Easy to operate, long service life, high productivity, patented product, automatic, multi-functional, high precision

Core components : Bearing, motor, pump

After-sales service provided : Online support,Video technical support

Warranty : 1 Year

Name : Thread Rolling Machine

Model Number : M10-400

Voltage : 380V/440V/415V,50HZ/60HZ

Package : wooden case

Contact Now

Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production
Advanced automated solution integrating straightening, cutting, and thread forming processes for maximum efficiency and precision.
Key Features
  • Quick Die Change System allows die replacement in less than 10 minutes, adapting to multi-spec production.
  • Built-In Error Detection Sensor automatically stops the machine if material jams or parameter deviations occur.
  • Energy-Efficient Servo Motor consumes 28% less power than traditional motors, lowering electricity bills.
  • One-Click Operation Interface simplifies the production process, requiring minimal operator training.
Technical Specifications
Model

Max.Thread Diamete

(mm)

Max.U-Bolt Blank Length

(mm)

Main Motor(KW)

Straighten The Motor(KW)

Weight

(KG)

Capacity

(PCS/mm)

Volume(L*W*H)(m)
M5-60 5 60 4 1.5 950 45-70 1.5*0.9*1.5
M6-70 6 70 5.5 2.2 1100 45-70 1.65*1*1.6
M6-200 6 200 5.5 2.2 1850 45-60 1.65*1*1.6
M8-80 8 80 7.5 3 1800 45-70 2.3*1.5*1.86
M8-150 8 150 11 3 1850 45-70 2.5*1.5*1.95
M8-300 8 300 11 3 2200 45-60 2.5*1.5*1.95
M10-130 10 130 11 3 1900 45-70 2.55*1.5*1.95
M10-220 10 220 11 3 2300 45-70 2.55*1.5*1.95

M10-400

 10 400 11 3 2650 45-55 2.65*1.5*1.95

M10-500

 10 500 11 3 3100 35-55 2.75*1.5*1.95

M10-620

 10 620 11 3 3300 35-55 2.8*1.5*1.95

M12-160

 12 160 18.5 4 2700 40-60 2.8*1.5*2.25

M12-200

 12 200 18.5 4 2800 40-60 2.8*1.5*2.25

M12-300

 12 300 18.5 4 3300 40-60 2.9*1.5*2.25

M12-400

 12 400 18.5 4 3800 40-55 3.0*1.5*2.25

M12-500

 12 500 18.5 4 4300 35-45 3.2*1.5*2.35

M12-600

 12 600 18.5 4 4600 35-45 3.3*1.5*2.35

M14-200

 14 200 22 5.5 3850 45-60 2.9*1.5*2.4

M14-400

 14 400 22 5.5 4500 40-55 3.1*1.5*2.4

M14-500

 14 500 22 5.5 4700 35-45 3.2*1.5*2.4

M14-600

 14 600 22 5.5 5300 35-45 3.4*1.5*2.4

M16-200

 16 200 30 7.5 5700 40-50 3.2*1.95*2.65

M16-300

 16 300 30 7.5 6000 40-50 3.2*1.95*2.65

M16-400

 16 400 30 7.5 6300 35-45 3.2*1.95*2.65

M16-500

 16 500 37 7.5 6900 30-40 3.4*1.95*2.65

M20-400

 20 400 45 11 10000 35-45 3.5*2.05*3.2

M20-600

 20 600 45 11 11000 30-40 3.7*2.05*3.2

M24-600

 24 600 45 11 12000 30-40 3.8*2.2*3.2
Product Gallery
Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production
Key Advantages
Minimizes material waste to below 1.5% through precise cutting and forming technology, reducing raw material costs.
Factory & Exhibition Showcase
Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production
Industrial-Grade Thread Forming Equipment: Ideal for Mass Fastener Production
